Inside Oxigraf: The Science Behind Fast-Response Oxygen Sensors

How Speed and Stability Redefine Oxygen Measurement Performance

Introduction – When Seconds Define Safety and Precision

In every environment where oxygen is monitored — from research labs to aerospace systems — speed matters.
A delayed reading can mean wasted product, flawed data, or unsafe conditions that go unnoticed until it’s too late.

For Oxigraf, speed isn’t about convenience — it’s about seeing reality as it happens.
When oxygen levels shift, every second counts.

Why Response Time Matters

Most oxygen sensors are designed for accuracy, but few are designed for immediacy.
In oxygen control loops, where the analyzer’s output drives automated adjustments, even a small delay can cause overcorrection and instability.
When readings lag behind real conditions, systems chase their own errors instead of maintaining balance.

A truly fast oxygen analyzer provides feedback fast enough to track — not trail — the process.
That difference defines control stability, product consistency, and, ultimately, safety.

The Physics of Response – Why Traditional Sensors Lag Behind

Most analyzers today rely on electrochemical or paramagnetic principles.
Both measure oxygen concentration effectively, but both add physical or chemical lag that slows response time.

• Electrochemical sensors depend on oxygen reacting with an internal electrolyte to generate current. This takes 5–15 seconds to stabilize, and the delay grows as the sensor ages or temperature changes.
• Paramagnetic sensors use gas diffusion into a measurement chamber and magnetic detection. They’re non-consumptive, but still take 2–6 seconds to settle after a sudden change.

Both designs measure accurately — eventually.
But when process dynamics shift in real time, those extra seconds can hide what’s really happening.

Laser-Based Sensing – Speed at the Speed of Physics

Oxigraf’s sensors use Tunable Diode Laser Absorption Spectroscopy (TDLAS) — a purely optical method.
A laser beam passes through the gas stream, and the sensor measures how oxygen molecules absorb specific wavelengths of light.
The result is an instantaneous, real-time readout with no chemical reactions, no diffusion lag, and no consumable components.

The system isn’t limited by chemistry — only by the speed of light and electronics processing.
With sampling rates up to 10 times per second, Oxigraf analyzers achieve a full-scale response in under one second, typically 0.3–0.5 seconds depending on flow and configuration.

That’s up to ten times faster than competing technologies.

This speed allows Oxigraf sensors to capture short-lived events — pressure spikes, purge transitions, oxygen ingress — that slower analyzers completely miss.

Four-Port Sampling – Measuring More, Waiting Less

Speed isn’t just about the sensor itself — it’s also about how the system moves air.
Oxigraf’s optional four-port sampling configuration multiplies performance by allowing multi-point sampling from several locations with almost no delay.

The four-port manifold routes gas sequentially through a single laser sensor, with internal switching and optimized flow control.
Each port can be sampled in rapid succession, giving a total wraparound time under one second — faster than most single-sample systems.

In practice, that means one analyzer can monitor four different zones — for example, multiple chambers in a lab, or multiple stages in a production line — in true real time.
Each port uses the same stable non-depleting laser sensor, ensuring consistency without drift or cross-calibration errors.

The result: one sensor, four data points, continuous truth.

Measure more. Wait less.

Why Speed Matters – Control, Safety, and Stability

In a feedback control system, data latency becomes instability.
When the signal lags, operators and controllers overcorrect — causing oscillations that waste oxygen, distort readings, or jeopardize product quality.

With near-instant feedback, Oxigraf’s laser sensors allow tighter control parameters and smoother, more stable operation.
They provide:

• True real-time gas monitoring with no delay between condition and correction.
• Stable oxygen control loops that eliminate overshoot and hunting.
• Reliable safety margins in oxygen-enriched or inerting systems.

Because the sensors are non-depleting and immune to humidity or temperature drift, they maintain their response speed and accuracy for 10 years or more.
That means fewer calibrations, less downtime, and data that stays trustworthy over the long term.

Applications – When Fast Means Safer

Fast-response oxygen sensing makes a measurable difference in any process that depends on timing:

• Aerospace and flight systems – Instant oxygen feedback in cabin and propulsion testing.
• Semiconductor manufacturing – Detecting oxygen ingress during purge cycles before yield is affected.
• Biotech and pharma – Stable, real-time oxygen control in sensitive bioreactors.
• Laboratory environments – Multi-point deficiency monitoring with four-port sampling.

In each case, Oxigraf’s speed turns measurement into insight — and reaction into prevention.

Conclusion – Precision in Real Time

Speed without stability is noise.
Stability without speed is blindness.
Oxigraf’s laser-based sensors deliver both — immediate, drift-free oxygen measurement that reflects the world as it is, not as it was seconds ago.

By combining TDLAS precision, four-port sampling, and non-depleting design, Oxigraf provides the fastest, most reliable oxygen analysis available.

Oxigraf continues to redefine precision in oxygen measurement — because in every system that matters, accuracy is everything.
